CP50 Pump Controller

CP50 Pump Controller


CP50 Pump Controller

Product Description

This is a system controller that controls a pump.
<Features>

  • A 3-digit digital timer can be used to set the suction and dispense times.
  • A dispense end signal output is provided as standard equipment.
  • By switching the operation mode, it can be operated by external signals.
  • The 0.01-second digital quartz timer provides good reproducibility of settings and stable timer time.
  • The shot switch allows confirmation of dispense even when the unit is installed in a dedicated machine. (Only in the case of interval mode)

Specifications

Control method Air pressure – Electronic control
Power supply AC100V or AC200~240V±10% 50/60Hz
Power consumption 7VA or less (at 100V AC)
Timer 0.01 to 9.99 seconds (digital setting)
Pressure adjustment range 0.01 to 0.7MPa
Operating capacity 400 times/min
External dimensions 161 (W) x 180 (D) x 120 (H) mm
Weight 2.3kg
