Features of
Hibar Pumps

Features of Hibar Pumps
Explained in Videos

Achieving High-precision Metering

Hibar Pumps can maintain stable metering accuracy of within ±0.5% (nominal value depending on the liquid and filling volume), even when there are changes in the temperature or viscosity of the liquid. They are particularly effective in situations that demand high precision.

Anti-drip Measures

By using a shut-off nozzle, it is possible to dispense stringy or slurry liquids more reliably without drips.

Prevention of Foreign Matter and Impurity Contamination

We offer a lineup of Pharma pumps that do not use any seals in the sliding surface. This prevents the intrusion of foreign matter and impurities.

Easy Parts Replacement

Hibar Pumps have separate blocks for the parts that come into contact with the liquid (wetted parts) and the parts that drive the plunger (drive parts). For daily cleaning, only the wetted parts need to be disassembled and the parts can easily be replaced or cleaned.

Explosion Proof

Using pnuematic drive, it is suitable for explosion-proof areas and environments with water.

Ease of Operation

With pnuematic drive, the dispense volume and speed can be easily adjusted using a micrometer or needle valve. In the case of motor drive, the dispense volume and speed can be controlled by setting values from external signals, such as a PC.

Find Products Based on Three Selection Points

List of Hibar Pump Products
